Python Figure Reference: splom Traces

A plotly.graph_objects.Splom trace is a graph object in the figure's data list with any of the named arguments or attributes listed below.

Splom traces generate scatter plot matrix visualizations. Each splom `dimensions` items correspond to a generated axis. Values for each of those dimensions are set in `dimensions[i].values`. Splom traces support all `scattergl` marker style attributes. Specify `layout.grid` attributes and/or layout x-axis and y-axis attributes for more control over the axis positioning and style.

  • name
    Code: fig.update_traces(name=<VALUE>, selector=dict(type='splom'))
    Type: string

    Sets the trace name. The trace name appears as the legend item and on hover.

  • visible
    Code: fig.update_traces(visible=<VALUE>, selector=dict(type='splom'))
    Type: enumerated , one of ( True | False | "legendonly" )
    Default: True

    Determines whether or not this trace is visible. If "legendonly", the trace is not drawn, but can appear as a legend item (provided that the legend itself is visible).

  • showlegend
    Code: fig.update_traces(showlegend=<VALUE>, selector=dict(type='splom'))
    Type: boolean
    Default: True

    Determines whether or not an item corresponding to this trace is shown in the legend.

  • legend
    Code: fig.update_traces(legend=<VALUE>, selector=dict(type='splom'))
    Type: subplotid
    Default: legend

    Sets the reference to a legend to show this trace in. References to these legends are "legend", "legend2", "legend3", etc. Settings for these legends are set in the layout, under `layout.legend`, `layout.legend2`, etc.

  • legendrank
    Code: fig.update_traces(legendrank=<VALUE>, selector=dict(type='splom'))
    Type: number
    Default: 1000

    Sets the legend rank for this trace. Items and groups with smaller ranks are presented on top/left side while with "reversed" `legend.traceorder` they are on bottom/right side. The default legendrank is 1000, so that you can use ranks less than 1000 to place certain items before all unranked items, and ranks greater than 1000 to go after all unranked items. When having unranked or equal rank items shapes would be displayed after traces i.e. according to their order in data and layout.

  • legendgroup
    Code: fig.update_traces(legendgroup=<VALUE>, selector=dict(type='splom'))
    Type: string
    Default: ""

    Sets the legend group for this trace. Traces and shapes part of the same legend group hide/show at the same time when toggling legend items.

  • legendgrouptitle
    Code: fig.update_traces(legendgrouptitle=dict(...), selector=dict(type='splom'))
    Type: dict containing one or more of the keys listed below.
    • font
      Code: fig.update_traces(legendgrouptitle_font=dict(...), selector=dict(type='splom'))
      Type: dict containing one or more of the keys listed below.

      Sets this legend group's title font.

      • color
        Code: fig.update_traces(legendgrouptitle_font_color=<VALUE>, selector=dict(type='splom'))
        Type: color
      • family
        Code: fig.update_traces(legendgrouptitle_font_family=<VALUE>, selector=dict(type='splom'))
        Type: string

        HTML font family - the typeface that will be applied by the web browser. The web browser can only apply a font if it is available on the system where it runs. Provide multiple font families, separated by commas, to indicate the order in which to apply fonts if they aren't available.

      • lineposition
        Code: fig.update_traces(legendgrouptitle_font_lineposition=<VALUE>, selector=dict(type='splom'))
        Type: flaglist string. Any combination of "under", "over", "through" joined with a "+" OR "none".
        Examples: "under", "over", "under+over", "under+over+through", "none"
        Default: "none"

        Sets the kind of decoration line(s) with text, such as an "under", "over" or "through" as well as combinations e.g. "under+over", etc.

      • shadow
        Code: fig.update_traces(legendgrouptitle_font_shadow=<VALUE>, selector=dict(type='splom'))
        Type: string
        Default: "none"

        Sets the shape and color of the shadow behind text. "auto" places minimal shadow and applies contrast text font color. See https://developer.mozilla.org/en-US/docs/Web/CSS/text-shadow for additional options.

      • size
        Code: fig.update_traces(legendgrouptitle_font_size=<VALUE>, selector=dict(type='splom'))
        Type: number greater than or equal to 1
      • style
        Code: fig.update_traces(legendgrouptitle_font_style=<VALUE>, selector=dict(type='splom'))
        Type: enumerated , one of ( "normal" | "italic" )
        Default: "normal"

        Sets whether a font should be styled with a normal or italic face from its family.

      • textcase
        Code: fig.update_traces(legendgrouptitle_font_textcase=<VALUE>, selector=dict(type='splom'))
        Type: enumerated , one of ( "normal" | "word caps" | "upper" | "lower" )
        Default: "normal"

        Sets capitalization of text. It can be used to make text appear in all-uppercase or all-lowercase, or with each word capitalized.

      • variant
        Code: fig.update_traces(legendgrouptitle_font_variant=<VALUE>, selector=dict(type='splom'))
        Type: enumerated , one of ( "normal" | "small-caps" | "all-small-caps" | "all-petite-caps" | "petite-caps" | "unicase" )
        Default: "normal"

        Sets the variant of the font.

      • weight
        Code: fig.update_traces(legendgrouptitle_font_weight=<VALUE>, selector=dict(type='splom'))
        Type: integer between or equal to 1 and 1000
        Default: normal

        Sets the weight (or boldness) of the font.

    • text
      Code: fig.update_traces(legendgrouptitle_text=<VALUE>, selector=dict(type='splom'))
      Type: string
      Default: ""

      Sets the title of the legend group.

  • legendwidth
    Code: fig.update_traces(legendwidth=<VALUE>, selector=dict(type='splom'))
    Type: number greater than or equal to 0

    Sets the width (in px or fraction) of the legend for this trace.

  • opacity
    Code: fig.update_traces(opacity=<VALUE>, selector=dict(type='splom'))
    Type: number between or equal to 0 and 1
    Default: 1

    Sets the opacity of the trace.

  • ids
    Code: fig.update_traces(ids=<VALUE>, selector=dict(type='splom'))
    Type: list, numpy array, or Pandas series of numbers, strings, or datetimes.

    Assigns id labels to each datum. These ids for object constancy of data points during animation. Should be an array of strings, not numbers or any other type.

  • text
    Code: fig.update_traces(text=<VALUE>, selector=dict(type='splom'))
    Type: string or array of strings
    Default: ""

    Sets text elements associated with each (x,y) pair to appear on hover. If a single string, the same string appears over all the data points. If an array of string, the items are mapped in order to the this trace's (x,y) coordinates.

  • dimensions
    Code: fig.update_traces(dimensions=list(...), selector=dict(type='splom'))
    Type: list of dict where each dict has one or more of the keys listed below.
    • axis
      Parent: data[type=splom].dimensions[]
      Type: dict containing one or more of the keys listed below.
